EnGenius Fit Network Management Controller - FITCON-100
FIT Series Management Platform with 1 GbE LAN (PoE, 802.3af/at) + 1 GbE
LAN. Support Max 100pcs FIT AP and switches.
FitCon 100 Overview
The FitCon 100 is a powerful, cloud-managed security gateway designed to unify and safeguard business networks. With a quad-core ARM Cortex A53 processor, it ensures optimal performance for handling high-speed data and secure traffic. Supporting dual-WAN connections, load balancing, and failover, the FitCon 100 provides a robust solution for uninterrupted connectivity. This gateway includes advanced security features like Stateful Packet Inspection (SPI), multiple VPN options, and VLAN support, making it an ideal choice for enterprises looking for a secure and easily manageable networking solution.
The FitCon 100 excels in providing a seamless cloud-based management platform, enabling IT teams to manage and monitor the network from anywhere. It comes equipped with high-throughput VPN capabilities, supporting both site-to-site and client VPNs, and offers easy setup options for policy-based VPN configurations. With PoE+ functionality, it can power external devices like access points or IP cameras, enhancing deployment flexibility.
Key Features & Benefits:
- Quad-Core Processor: Ensures smooth performance for heavy network traffic.
- Dual-WAN Support: Allows load balancing and failover for uninterrupted internet connectivity.
- Advanced Security: Features Stateful Firewall, VPN encryption, and policy-based VPN management.
- PoE+ Support: Power over Ethernet for connecting external devices.
- Cloud Management: Manage from anywhere using an intuitive cloud-based interface.
- VLAN & Bandwidth Management: Customize network segmentation and bandwidth allocation easily.
- High VPN Throughput: Handles up to 1.2 Gbps for secure, fast connections.
This makes the FitCon 100 an excellent choice for businesses seeking a high-performance, secure, and easily manageable network gateway.
| Network Ports | 2 x 10/100/1000 RJ-45 Ethernet Ports |
| Operating Temperature | 0°C to 50°C |
| Operation Modes | Routed/Passthrough |
| Networking Functions | Static Routing VLAN Tagging Dynamic DNS Support Bandwidth Management DHCP client/server/relay |
| Firewall (SPI Throughput) | 5 Gbps |
| VPN Throughput | 1.2 Gbps |
| PoE Capable Ports | 1 x PoE+ (802.3af/at) |
| Brand | EnGenius |
| Dimensions | Width: 8.5 inches (215 mm) Length: 7.0 inches (178 mm) Height: 1.6 inches (40 mm) |
| Weight | 2.4 lbs (1.09 kg) |
| Package Contents | Power adapter Power cord RJ-45 Console Cable Wall Mount Kit Quick Installation Guide |
| Certifications | CE, FCC, IC |
| Humidity | 5% to 90% (non-condensing) |
| Warranty | 3 Years |
| Operating Frequency | 1.6 GHz |
| CPU Processor | Quad-Core ARM Cortex A53s |
| Memory | 4 GB DDR3 |
| Max. Concurrent VPN Tunnels | 250 |
| Max. TCP Concurrent Sessions | 1,500,000 |
| Storage | 16 GB Flash |
| USB Interface | 1 x USB 3.0 |
| Security Chip | TPM |
| Firewall Features | Stateful Packet Inspection (SPI) Policy Rules Port Forwarding 1:1 NAT Inbound/Outbound Filtering |
| VPN Features | Client VPN Policy-based VPN Auto VPN NAT traversal Dead Peer Detection (DPD) |
| Power | 48V/0.5A |
| Max. VLANs | 64 |
| VPN Encryption | DES, 3DES, AES (256-bit) |
| VPN Authentication | MD5, SHA1, SHA2 (512-bit) |
| VPN Key Management | IKEv1 (x-auth, mode-config) IKEv2 (EAP, configuration payload) |
| WAN Support | Dual WAN (load balancing and failover) WAN Load Balancing |
| Complaince | FCC Part 15 (Class B) CE EMC IC |
