Cloud-Managed VPN Router with 8x 2.5-Gigabit (4 PoE+) Ethernet ports and two SFP+ slots
SD-WAN Gatewaywith 4 x 2.5Gbps Ethernet ports + 4 x 2.5Gbps PoE + 2 x SFP+, IEEE802.3at/af, 120w PoE power budget, internal power supply, 13inch 1U rack-mountable
Power Up Your Network with the EnGenius ESG620 Cloud-Managed VPN Router
Limited Time Offer!
Upgrade your network infrastructure with the EnGenius ESG620 and experience the power of a high-performance VPN router. This advanced device provides centralized management, exceptional connectivity, and robust security features to optimize your network performance.
Benefits of the ESG620:
Optimize Network Performance: Improve application delivery and reduce latency with SD-WAN.
Centralized Management: Manage your network from anywhere with EnGenius' cloud-based platform.
High-Speed Connectivity: Connect multiple devices with eight 2.5-Gigabit Ethernet ports.
Power Compatible Devices: Use PoE+ to power devices without additional power adapters.
Expand Your Network: Add fiber optic connections with the SFP+ slots.
Enhanced Security: Protect your network from threats with built-in security features.
The EnGenius Cloud Managed ESG620 Security Gateway is designed for small to medium-sized businesses to ensure secure, reliable, and high-performance network access. This gateway integrates routing, firewall, VPN, and other security features in a single device, centrally managed through the EnGenius Cloud platform. The ESG620 provides comprehensive network protection while enabling businesses to manage their network remotely with ease.
| Network Ports | 8 x 2.5-Gigabit Ethernet Ports (4 PoE+), 2 x 10/100/1000 RJ-45 WAN Ports |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Operation Modes | Routed/Passthrough |
| Networking Functions | Static Routing, VLAN Tagging, Dynamic DNS Support, Bandwidth Management, DHCP client/server/relay |
| Firewall (SPI Throughput) | 2 Gbps |
| VPN Throughput | 650 Mbps |
| PoE Capable Ports | 4 x 2.5-Gigabit Ethernet Ports (802.3af/at) |
| Brand | EnGenius |
| Dimensions | Width: 8.0 inches (203 mm), Length: 6.5 inches (165 mm), Height: 1.5 inches (38 mm) |
| Weight | 2.1 lbs (0.95 kg) |
| Package Contents | Power Adapter, Power Cord, RJ-45 Console Cable, Wall Mount Kit, Quick Installation Guide |
| Certifications | CE, FCC, IC |
| Humidity | 5% to 95% (non-condensing) |
| Warranty | 2 Years |
| Operating Frequency | 2.0 GHz |
| CPU Processor | Quad-Core |
| Memory | 4 GB |
| Max. Concurrent VPN Tunnels | 50 |
| Max. TCP Concurrent Sessions | 500,000 |
| Storage | 16 GB Flash |
| USB Interface | 1 x USB 3.0 |
| Security Chip | TPM |
| Firewall Features | Client VPN, Policy-based VPN, Auto VPN, NAT Traversal, Dead Peer Detection (DPD) |
| Power | 54V/1.2A |
| Regulatory Compliance | FCC Part 15 (Class B), CE, EMC, IC |
| Max. VLANs | 32 |
| VPN Encryption | DES, 3DES, AES (256-bit) |
| VPN Authentication | MD5, SHA1, SHA2 (512-bit) |
| VPN Key Management | IKEv1 (x-auth, mode-config), IKEv2 (EAP, configuration payload) |
| WAN Support | Dual WAN (load balancing and failover) WAN Load Balancing |
