EnGenius:ECW160
EnGenius Cloud Management AP, 11ac wave2/a/b/g/n, Dual Band Concurrent..Outdoor AP, 1 x 10/100/1000 Mbps LAN Port, 23dBm @ 2.4GHz,..23dBm @ 5GHz, 4 x SMA connector, 802.3af.
Upgrade Your Wi-Fi with the EnGenius ECW160
Limited Time Offer!
Experience the power of Wi-Fi 6 in a compact and stylish package. The EnGenius ECW160 is the perfect solution for homes and small offices that need a reliable and high-performance Wi-Fi access point.
Benefits of the ECW160:
Faster Speeds: Enjoy seamless streaming, gaming, and video conferencing.
Improved Efficiency: Handle multiple devices simultaneously without performance degradation.
Compact Design: Easily mount the ECW160 anywhere without taking up much space.
Easy Installation: Set up your Wi-Fi network in minutes.
Cloud Management: Control your Wi-Fi network from anywhere.
The EnGenius ECW160 is a sleek and compact indoor Wi-Fi 6 access point that delivers high-speed performance and reliable connectivity. Despite its small size, the ECW160 packs a powerful punch, offering dual-band technology and support for the latest Wi-Fi 6 standard.
Key Features:
- Wi-Fi 6 Technology: Experience faster speeds, lower latency, and improved efficiency with Wi-Fi 6.
- Dual-Band Connectivity: Connect to both 2.4 GHz and 5 GHz networks for optimal performance.
- Compact Design: Easily mount the ECW160 on walls or ceilings without taking up much space.
- Easy Installation: Set up your Wi-Fi network in minutes with the included mounting accessories and user-friendly interface.
- Cloud Management: Manage your access point remotely through EnGenius' cloud-based platform.
| Operation Modes | AP, Mesh |
| Brand | EnGenius |
| Power Source | Power-over-Ethernet: 802.3at Input 12VDC / 2A |
| Physical Interface | 1 x 10/100/1000 N-BASE-T, RJ-45 Ethernet Port 1 x DC Jack 1 x Reset Button |
| LED Indicators | 1 x Multi-color LED |
| MU-MIMO | Two (2) spatial streams for simultaneous connections |
| Antenna | 2 x 2.4 GHz: 5 dBi 2 x 5 GHz: 5 dBi Integrated Omni-Directional Antenna |
| Transmit Power | Up to 20 dBm on 2.4 GHz Up to 20 dBm on 5 GHz |
| Management Options | Multiple BSSID: 8 SSIDs for both 2.4 GHz and 5 GHz VLAN Tagging: 802.1q SSID-to-VLAN Tagging SNMP: v1, v2c, v3 |
| Package Contents | 1 x EnGenius ECW160 Cloud Managed Indoor Access Point 1 x Ceiling Mount Base (9/16” Trail) 1 x Ceiling Mount Base (15/16” Trail) 1 x Ceiling and Wall Mount Screw Kits 1 x Quick Installation Guide |
| Certifications | FCC, CE, IC |
| Warranty | 1 Year |
| Standards | IEEE 802.11ax on 2.4 GHz and 5 GHz Backward compatible with 802.11a/b/g/n/ac |
| Processor | Qualcomm® Dual-Core ARM Cortex A53 |
| Operating Frequency | Dual-Radio Concurrent 2.4 GHz & 5 GHz |
| SU-MIMO | Two (2) spatial streams for both 2.4 GHz and 5 GHz |
| Channelization | Supports VHT 20/40/80 MHz for 802.11ax and 802.11ac |
| Wireless Security | WPA3, WPA2 Enterprise (AES), WPA2 AES-PSK MAC Address Filtering (up to 32 MACs per SSID) |
| Maximum Power Consumption | 15.4W |
| Radio Chains/Spatial Stream | 2x2:2 |
| Supported Data Rates (Mbps) | 802.11ax: 2.4 GHz: 9 to 1200, 5 GHz: 18 to 2400 802.11b: 1, 2, 5.5, 11 802.11a/g: 6, 9, 12, 18, 36, 48, 54 802.11n: 6.5 to 300 802.11ac: 6.5 to 867 |
| Dimensions & Weights | Device Weight: 0.83 lbs (380 g) Length: 6.30" (160 mm) Width: 6.30" (160 mm) Height: 1.18" (30 mm) Packaging Weight: 1.10 lbs (500 g) Length: 10.35" (263 mm) Width: 6.41" (163 mm) Height: 1.49" (38 mm) |
