Cloud Managed 8-Port 10 Gigabit Switch with 4 SFP+ Ports
Cloud Management SFP+ Switch 12xSFP+ Port Fiber Switch, 1xConsole Port & 2 LED
Power Up Your Network with the EnGenius ECS5512F
Limited Time Offer!
Upgrade your network infrastructure with the EnGenius ECS5512F Cloud-Managed 12-Port 10 Gigabit SFP+ Half-Rack Aggregate Fiber Switch. This powerful switch provides centralized management, high-speed connectivity, and flexibility for fiber-optic networks.
Benefits of the ECS5512F:
Centralized Management: Manage your network from anywhere with EnGenius' cloud-based platform.
High-Speed Connectivity: Connect to high-speed fiber optic networks.
Scalability: Expand your network capacity by stacking multiple switches.
Optimized Network Performance: Benefit from advanced Layer 2 and some Layer 3 features.
Enhanced Security: Protect your network with built-in security features.
Specifications:The EnGenius cloud-managed ECS5512F 12-port 10 Gigabit SFP+ half-rack aggregate fiber switch, expandable to two per rack, boosts traffic flow and network performance. Administrators can easily scale from 12 to 24 SFP+ ports on a single rack as network demands increase in large business, multi-dwelling unit, hospitality, and campus environments.
|
| Network Ports | 12 SFP+ Ports , Link/Activity/Speed (per SFP slot) |
| Temperature Range | Operating: 32ºF~122ºF (0 ºC~50 ºC) |
| Trust Mode | Cos/802.1p DSCP CoS/802.1p-DSCP |
| Brand | EnGenius |
| Switching Capacity | 240Gbps |
| SDRAM | 512MB |
| Flash Memory | 128MB |
| Power Source | 100 ~ 240VAC, 50-60Hz |
| LED Indicators | Power LED Fault LED |
| Multiple IP Interface | 20 IPv6 address |
| ARP Table | Max. 192 ARP entries |
| Static ARP | Static 192 ARP entries |
| IPv4 Static Route | Max. 63 entries |
| IPv6 Static Route | Max. 21 entries |
| Package Contents | 1x Cloud Managed Fiber Switch 1x Quick Installation Guide 1x Power Cord 1x RJ45 Console Cable 1x Half-Rack Mount Kit 1x 1U Rack Mount Kit |
| Certifications | FCC, CE, IC |
| SNMP | SNMP v1/v2c/v3 Support |
| Packaging | Weight: 2.6kg (5.74 lbs.) Width: 330mm (13”) Length: 350mm (13.78”) Height: 130mm (5.12”) |
| Humidity (non-condensing) | Operating: 5% - 90% |
| Dimensions & Weights Device | Weight: 1.39kg (3.07 lbs.) Width: 210mm (8.27”) Length: 230mm (9.06”) Height: 44mm (1.74”) |
| Port Standards | 802.3 10Base-T Ethernet 802.3u 100Base-TX Ethernet 802.3ab 1000Base-T Ethernet 802.3bz 2.5G Base-T Ethernet 802.3x Full-Duplex Flow Control |
| MAC Address Table | 16K |
| Jumbo Frame | 9K |
| Multicast Group | Max 256 groups |
| Port Security | Max. 256 Entries |
| SSL Certificate | Certificate/Key Import |
| Access Control List (ACL) | Ingress MAC Based ACL IPv4/IPv6 Based ACL ACL Binding Action: Permit/Deny Time base ACL |
| RMON | RMON 1,2,3,9 |
| Network Management | EnGenius Cloud Local Web GUI |
| MLD SnoopingD | MLD Snooping: v1 |
| QoS-Number of Priority Queues Supported | Queue 8 |
| Scheduling Mechanism | Strict / WRR/ Strict + WRR |
| Bandwidth Control | Port-based bandwidth control (Ingress/ Egress) |
| Web Graphical User Interface (GUI) | HTTP IPv4 / IPv6 HTTPS IPv4 / IPv6 |
| System Time | Time Setting/Daylight saving |
| Common L2 Features | 802.1d Spanning tree Loopback Detection Multicast Filtering Multicast Group IGMP Multicast Forwarding IGMP Snooping MLD Multicast Forwarding 802.1Q VLAN tagging 802.3x flow control 802.3ad Link Aggregation IPv4 DHCP Relay IPv4 DHCP Snooping IPv4 DHCP Snooping Source MAC Address Check-up ARP Inspection ARP Packet Validation (additional validation checks) Voice VLAN Port-based VLAN Protocol-Based VLAN Dynamic VLAN VLAN Group CoS Mapping 802. 1X Radius Authentication Protocol IPv4 Settings IPv6 Settings IEEE 802. 3az Energy Efficient Ethernet (EEE) Command Line Interface (CLI) SSH Server Telnet Server TFTP Client Configuration Upgrade/Backup Simple Network Time Protocol (SNTP) SYSLOG |
